| Ask Lasest Price | |
| Brand Name : | STARPAI |
| Model Number : | 101-1-3.5 |
| Certification : | EC,UL,Rohs |
| Price : | 1 usd |
| Delivery Time : | 25 days after 100% T/T payment |
| Payment Terms : | T/T |
| Supply Ability : | 100000K/pcs |

| Pitch | 3.50mm |
|---|---|
| Poles | 2-24 Pin |
| Material | |
| Case | PA66,UL94V-0 |
| Brass hole | Brass,Tin plated |
| Protector | Stainless steel |
| Screw | M2,C1018 steel,Zinc plated |
| Electrical | |
| Voltage | 250 V |
| Current rating | 10A |
| Electrical Withstanding | AC2000V,1minute |
| Isolation resistance | DC500V 500MΩ |
| Wire range | 24 -16 AWG |
| Max Torque | 2.5kgf.cm |
| Mechanical | |
| Operation temperature | - 33℃~+105℃ |
| Strip length | 5-6mm |
|   |
